Single Steel Door Designer – Prices Ex. VAT, Inc. 2.5% MCD

Project details

Click To Select Your Door's Configuration

Click To Select Your Door's Configuration

The image provided is representational – please refer to your order for specifications and if you require a technical drawing, please contact our team once you have placed your order

This is the base of your door. You'll add hardware, pick options, and change colour in the next steps.

Your door includes;

  • Heavy Duty Galvanised Steel Double Door with Astragal
  • Heavy Duty Galvanised Steel Single Rebate Frame
  • Weather Seals
  • Stainless Steel Hinges with Dog Bolts
  • Threshold
  • Any Standard Colour PPC Finish
Do You Require A Security / General Purpose Door or a Fire Exit?

Do You Require A Security / General Purpose Door or a Fire Exit?

For emergency exits of any kind that require panic hardware (e.g. push bars) please select fire exit. For any general purpose or security door, please select Security / General Purpose Door

Single Door - Structural Opening*

Single Door - Structural Opening

The structural opening is the brick-to-brick dimensions of the aperture your door fits into. To measure, take 6 measurements of the aperture (top, middle, bottom horizontally and left, middle, right vertically). If the aperture is slightly out of square, we would recommend using the smallest measurements to ensure square fit.

Your overall door frame size will be 6-10mm smaller than your structural opening size on width and height to allow for fitting.  If you require a different tolerance, please contact the team to discuss.

Single Door Hinge Side - As Viewed From The Pull Side

Single Door Hinge Side - As Viewed From The Pull Side

Select the side the hinges are on, as you pull the door open towards you.

Single Door Opening Direction - As Viewed From The Pull Side

Single Door Opening Direction - As Viewed From The Pull Side

If the door opens inwards, the door opens into the building. The door opens outwards when it opens out and away from the building. If you are unsure, please contact us.

Please note that fire exits should open outwards only. If you require an emergency exit that opens inwards, please contact the team.

Are You Within 25 Miles Of A Water Source?

Are You Within 25 Miles Of A Water Source?

We Recommend The Marine Grade PPC Upgrade For Doors Close To Water. This Significantly Improved Longevity In Coastal Settings.

Select No If You Are Close To Water But You'd Rather Have Standard PPC. Please Note, This May Invalidate Your Warranty.

Door Colour

Door Colour

Due To Screen Settings, The Visible Colour May Vary From The Final Product. Colours Shown Are For Example Purposes Only.

Custom door colours may require a price uplift - this will be confirmed prior to manufacture.

Custom PPC Colour

Does Your Single Door Require A Fire Rating?

Does Your Single Door Require A Fire Rating?

A Closer Is Required On All Fire Rated Doors. Fire Rating Is Dependant On Leaf Area & Will Be Confirmed Prior To Manufacture.

Single Doors Under 1100mm Wide and Double Doors Under 2200mm Wide Can Be Fitted With Geze 2000 Closers. All Wider Doors Require Geze 4000 Closers.

Does Your Single Door Require A Fire Rating?

Does Your Single Door Require A Fire Rating?

A door closer is mandatory on all fire rated doorsets, and the door is fire rated from the side that the door closer is on. If you are unsure of which side, you require the fire protection from, please contact the team for assistance.

Fire resistance may be affected by hardware selections, please contact the team if you are uncertain.

Single Door Middle Lock & Handles

Single Door Additional Upper Lock None

Single Door Additional Lower Lock

Single Door Maglock

Single Door Middle Lock & Handles

Single Door Additional Upper Lock

Single Door Additional Lower Lock

Single Door Maglock

Single Door Escape Hardware Type

Single Door Panic Hardware Options

Single Door Closer

Single Door Closer

Single Door Letter Box

Single Door Spy Hole

Single Door Kick Plates

Does Your Single Door Require Weathering?

Does Your Single Door Require Weathering?

This is a Rain Deflector, a piece of material at the base of the door leaf Angled Away From The Aperture To Avoid Water Ingress.

Single Door Rain Deflector

Does Your Single Door Require Louvre Panels?

Does Your Single Door Require Louvre Panels?

Louvred panels allow for ventilation through the door leaf. These louvred panels come with insect mesh as standard. Should you require bird mesh, or have a free area requirement, please contact the team.

Choose Single Door Louvre Panel Size

Does Your Single Door Require Vision Panels?

Does Your Single Door Require Vision Panels?

Double Glazed With 2no 6.4mm Clear Laminated Glass Layers, Either Side Of A 6mm Spacer.

Choose Single Door Vision Panel Shape & Size

Does Your Single Door Require Vision Panels?

Does Your Single Door Require Vision Panels?

A vision panel is a window (glazed panel) set into the door leaf. This is recommended for high-traffic areas such as corridors, main entrances, and goods inwards doors.

Choose Single Door Vision Panel Shape & Size

Does Your Single Door Require Fire Rated Louvre Panels?

Does Your Single Door Require Fire Rated Louvre Panels?

Steel Louvre With Insect Mesh & Dampners, Approx. 52% Free Area.

Bird mesh or other options are non-standard so have to be quoted separately.

Choose Single Door Fire Rated Louvre Panel Size

Does Your Single Door Require Fire Rated Vision Panels?

Does Your Single Door Require Fire Rated Vision Panels?

Glazed With 9mm Firelite.

You Can Select Size & Placement Next

Choose Single Door Fire Rated Vision Panel Shape & Size

Does Your Single Door Require Fire Rated Vision Panels?

Does Your Single Door Require Fire Rated Vision Panels?

Glazed With 9mm Firelite.

You Can Select Size & Placement Next

You Can Select Size & Placement Next

Fixing Kit

Fixing Kit

A Fixing Kit includes plastic bung caps, fixings, a drill bit, and frame adjusting tool. Doors installed into brick, blockwork or concrete require a Masonry Fixing Kit. Doors installed into Steel/Aluminium require a steel fixings kit. Please note that fixings kit does not include foam fill or mastic. We do not recommend installing into timber due to door weight, however, this can be accommodated. Please contact our team if your door is to be installed into Timber.

Set of Steel Caps for Fixing Holes - PPC Finished To Match Door

Set of Steel Caps for Fixing Holes - PPC Finished To Match Door

Black Plastic Caps Provided As Standard
